Room thermostat type tr 11 - DIFF
Room thermostat type tr 11 - DIFF
Room thermostat type tr 11 - DIFF
Room thermostat type tr 11 - DIFF

Room thermostat type tr 11 - DIFF

ABS materialstrong and somewhat prone very aestheticApplication : Heating Air conditioning Ventilation Cut-off power : 10A 250V - Insulation class: IP20. Differential 0,4°C Setting range 6 to 30°C - Frost protective temperature: 5°C. Dimensions 73 x 73 xD 26mm Terminal protectingreversing contact : 2 Switches : The first one Summer/ Off/ Winter - The second one Automatic ventilation 2 speeds It can be installed in an embedded housing Response time: fast and no need for a proactive resistance for low currents such as 24V 2 removable pins to block and limit the temperature

Brand:
DIFF
€18.14 (tax excl.)
In Stock 3 products
Reference:
705310
  Download PDF
Add to wishlist
Description

ABS material ?strong and somewhat prone? very aesthetic ?Application : Heating Air conditioning Ventilation ? Cut-off power : 10A 250V - Insulation class: IP20. ? Differential 0,4°C ? Setting range 6 to 30°C - Frost protective temperature: 5°C. ? Dimensions 73 x 73 xD 26mm ? Terminal protecting ?reversing contact :? 2 Switches : The first one Summer/ Off/ Winter - The second one Automatic ventilation 2 speeds ? It can be installed in an embedded housing ? Response time: fast and no need for a proactive resistance for low currents such as 24V ? 2 removable pins to block and limit the temperature



Product Details
705310

Data sheet

FAB_COM_EQ
ORIGINE FABRICANT
