Domestic circulator ups25-80 n 180 1x230 50hz 9h- GRUNDFOS - 95906439
Complies with ErP/Eup. Simple circulator in stainless steel
Brand:
€437.84
(tax excl.)
Reference:
Download PDF
95906439/GR
Add to wishlist
| Garantie | 2 | |
| Insulation | F | |
| Logo Marque | GRUNDFOS | |
| Protection | X2D | |
| Power (W) | 165.0 | |
| Flow Rate (m³/h) | 5.0 | |
| Ø | M1"1/2 | |
| DN | 25.0 | |
| Center-to-Center Distance (mm) | 180 | |
| Specifications | 4.56m (Hmt) - 80 dm maxi | |
| Power Supply / Voltage | 230V | |
| PN (bar) | 10 | |
| Package Height (m) | 0.205 | |
| Package Width (m) | 0.205 | |
| Package Length (m) | 0.205 | |
| Package Weight (kg) | 4.942 | |
| Thread size | Pas de filetage de tuyau |
95906439/GR
Data sheet
- FAB_COM_EQ
- ORIGINE FABRICANT
- Garantie
- 2
- Insulation
- F
- Logo Marque
- GRUNDFOS
- Protection
- X2D
- Power (W)
- 165.0
- Flow Rate (m³/h)
- 5.0
- Ø
- M1"1/2
- DN
- 25.0
- Center-to-Center Distance (mm)
- 180
- Specifications
- 4.56m (Hmt) - 80 dm maxi
- Power Supply / Voltage
- 230V
- PN (bar)
- 10
- Package Height (m)
- 0.205
- Package Width (m)
- 0.205
- Package Length (m)
- 0.205
- Package Weight (kg)
- 4.942
- Thread size
- Pas de filetage de tuyau
