Submersible pump INITIAL DRAIN 10-7- WILO - 4168021

Submersible pump INITIAL DRAIN 10-7- WILO - 4168021

Name: Submersible pump INITIAL DRAIN 10-7- WILO - 4168021
Brand: WILO
SKU: 4168021/WI
Price: 140.94 EUR
Availability: InStock

Brand:

€140.94 (tax excl.)

In Stock 6 products

Reference:

4168021/WI

Download PDF

Add to wishlist

Description
Caracteristique

Description

Submersible pump for stationary submersed installation and transportable in fully automatic operation due to a fitted float switch.
Hydraulic
The discharge side connector is an Rp 1-1/2" horizontal threaded orifice
Motor
Immersed motor in AC version and integrated thermal protection with automatic restart.
Automatic mode due to the float-switch Exceptional reliability due to a robust material and double sealing ring Liquid temperature range: 5...35°C Immersion depth: 5m Size grading: 5mm Cable length: 10m

Caractéristiques

Garantie	3
Intensité	3A
Isolation	F
Logo Marque	WILO
Protection	IP68
Vitesse (tr/min)	2900
Débit (m3/h)	13.0
Ø	F1"1/2
Caractéristiques	Hauteur refoulement max. 7m
Alimentation / Tension	230V
PN (bar)	3
