LGV 80S A1H kit - HUBACONTROL : RD4213B
USE :
Kit specially designed for checking the ventilation shaft neatness or the filter neatness.
FEATURES :
Cut-off power 1,5A - 250V
Change-over contact
Temperature : -30 to +110°C
Connection with connector DIN.
Connection with teats 6,2mm
KIT composed with : 1 differential pressure switch LGV80SA1H for fixed adjusting
to 80Pa (0,8 mbar).
1 fixing plate.
2 meters of PVC hose.
1 piercing gauge.
2 fixing flanges 6,2mm
Fixing screw.
Protection IP42
Kit specially designed for checking the ventilation shaft neatness or the filter neatness.
FEATURES :
Cut-off power 1,5A - 250V
Change-over contact
Temperature : -30 to +110°C
Connection with connector DIN.
Connection with teats 6,2mm
KIT composed with : 1 differential pressure switch LGV80SA1H for fixed adjusting
to 80Pa (0,8 mbar).
1 fixing plate.
2 meters of PVC hose.
1 piercing gauge.
2 fixing flanges 6,2mm
Fixing screw.
Protection IP42
Safety Information :
To protect yourself against electrical hazards, be sure to disconnect the load from the power supply before working on it. If in doubt, don't risk a faulty installation: ask a qualified electrician for advice.
