Flange motor nema2 non-ventilated 1phase 220v 250w
Flange néma 2. Monophased motors entirely closed up to 1/4 of the CV (185 watts). Semi open for the superior powers. Smooth and silent landings. Start up with the capacitor for the monophase. Two senses of the rotation on plate with incorporated limits: the sense of the rotation should be observed while the shaft is towards one self. Model with flange Néma 2:Fitting :Ø162mm; Center distance of fixation : 184mm Shaft : Ø12.7mm x 57mm up to 3/4CV.
€235.31
(tax excl.)
Reference:
Download PDF
702094
Add to wishlist
Flange néma 2. Monophased motors entirely closed up to 1/4 of the CV (185 watts). Semi open for the superior powers. Smooth and silent landings. Start up with the capacitor for the monophase. Two senses of the rotation on plate with incorporated limits: the sense of the rotation should be observed while the shaft is towards one self. Model with flange Néma 2 : Fitting :Ø162mm Center distance of fixation : 184mm Shaft : Ø12.7mm x 57mm up to 3/4CV.
Loading...
This product can be fitted to the models listed below. :
See more
Loading in progress...
