Lug butterfly valve D125 - DIFF

Name: Lug butterfly valve D125 - DIFF
Brand: DIFF
SKU: 110178
Price: 75.65 EUR
Availability: InStock

Nominal Diameter 125 and Nominal Pressure 16

Brand:

€75.65 (tax excl.)

Last items in stock 2 products

Reference:

110178

Download PDF

Add to wishlist

Description
Installed on models ...

Description

For use with cold water and hot water Temperature limits: -10°C to +110°C With EPDM seals GJS-500 brass body ISO 5211 mounting pad 10-position notched aluminium lever, lockable at 2 levels Standardisation: Directive 97/23/EC: EC Number 0035 Nickel-plated GJS-400-15 brass butterfly - climate engineering model

Product Details

Reference 110178

Data sheet

FAB_COM_EQ: ORIGINE FABRICANT

Installed on models ...
