Neck flange 80 PN10- DIFF - 110190
Steel collared flange for welding raised upright joint face 4004 PN10 Manufacturing according to EN 1092-1 standards Marking: A mark is made on each flange Commercial brand, standards, Nominal pressure type, DN, Material, Batch No.
Brand:
€16.89
(tax excl.)
Reference:
Download PDF
110190
Add to wishlist
| F (mm) | 20.0 | |
| Fixation | M16 | |
| H (mm) | 2.0 | |
| Ø | 138 | |
| DN | 80.0 | |
| E (mm) | 50.0 | |
| Caractéristiques | PN : 10-16 | |
| D (mm) | 18.0 | |
| A (mm) | 200.0 | |
| Application | PN : 10-16 | |
| B (mm) | 160.0 | |
| C (mm) | 88.9 | |
| G (mm) | 138 | |
| Nombre | 8 | |
| Norme | EN1092_1 | |
| Type | BW11/B | |
| Hauteur emballage (m) | 0.052 | |
| Largeur emballage (m) | 0.205 | |
| Longueur emballage (m) | 0.205 | |
| Poids emballage (kg) | 4 |
