Female thread or press connection (22 mm) Connection on horizontal pipe NBR EPDM rubber and brass body With levers in polypropylene resin Cartridge: AISI 302 stainless steel Spring: AISI 302 stainless steel Usable fluid: Water - Water + Glycol 30% Maximum fluid temperature: 110°C Maximum operating pressure: 10 bar (1000 kPa) Maximum discharge pressure: 10 bar (1000 kPa)
Female thread or press connection (22 mm) Connection on horizontal pipe NBR EPDM rubber and brass body With levers in polypropylene resin Cartridge: AISI 302 stainless steel Spring: AISI 302 stainless steel Usable fluid: Water - Water + Glycol 30% Maximum fluid temperature: 110°C Maximum operating pressure: 10 bar (1000 kPa) Maximum discharge pressure: 10 bar (1000 kPa) Connector F 3/4 UNI-EN-ISO-228
